A compact random orbital sander for controlled finishing with a 150 mm pad.
The Atlas Copco LST30 is a pneumatic random orbital sander built for clean, consistent surface finishing in assembly and production environments.
The family combines 9,000 free speed rpm, an 8 mm orbit and a 150 mm pad size, giving operators a practical balance of coverage, control and finishing quality.
How do I choose between the LST30 models?
Step 1: Choose the version that best suits your preferred grip and handling style.
Step 2: Check the air supply requirements in your line, including the 1/4 BSP inlet and 8 mm hose size.
Step 3: Match the tool setup to your finishing task and any dust extraction or productivity accessories you want to use.
What kind of work is the LST30 made for?
It is suited to finishing, sanding and surface smoothing tasks where controlled movement and even coverage matter.
What is included with the sander?
Included items are a Ø150 mm velcro pad, a lever for changing the pad, and a hose nipple for an 8 mm hose.
Can I connect dust extraction?
Yes.
Optional 1.8 m dust extraction hoses are available in Ø25 mm, Ø32 mm and Ø38 mm versions for different suction requirements.
What should I check before ordering?
Check the preferred model version, the air connection setup, and whether you need dust extraction hoses or the productivity kit for your application.
What is the difference between the H090-15 and S090-15 versions?
Both versions belong to the same LST30 family and share the core working data of the series.
The choice comes down to handling preference and the grip configuration you want.
| Model | Max free speed (r/min) | Max pad size (mm) | Orbit dia (mm) | Height over spindle (mm) | Air inlet thread (in) BSP (in) | Max output (W) | Weight (kg) | Air consumption at free speed (l/s) | Rec hose size (mm) | Handle (With) | (Without) | Ordering No. |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| LST30 H090-15 | 9000 | 150 | 8 | 118 | 1/4 | 300 | 1.2 | 7.5 | 8 | – | • | 8423036172 |
| LST30 S090-15 | 9000 | 150 | 8 | 118 | 1/4 | 300 | 1.1 | 7.5 | 8 | – | • | 8423036198 |
The complete accessories tables, exactly as they appear in the Atlas Copco catalog – every ordering number, dimension and drawing. The PDF attached to this page is also available for download.
The HADI Technologies team will help you select the right configuration, verify application requirements and provide technical information about Atlas Copco LST30 Pneumatic Random Orbital Sander.
