Clayton’s DuraLite is a line of pneumatic palm sanders in a durable aluminum housing with lower vibration, featuring a vibration-absorbing Comfort Grip, a Tip Valve, a full-floating polymer rotor, speed control and a bearing protection system.
Clayton’s DuraLite is a line of pneumatic palm sanders in a durable aluminum housing with lower vibration, featuring a vibration-absorbing Comfort Grip, a Tip Valve, a full-floating polymer rotor, speed control and a bearing protection system.
The Dual-Action / Random-Orbital (DA) motion spins the disc while moving in an ellipse to eliminate swirl marks. The Central Vac version requires a portable or central vacuum and ships with a 1in threaded vacuum port plus a 1in swivel adapter for any Clayton vacuum. Offered in three pad sizes and three orbits, with a J-Hook pad (J) or Vinyl pad (S).
| SKU | Select |
| Pad size | Select |
| Orbit | Select |
| Motion | Dual-Action / Random-Orbital (DA) |
| Dust mode | Central Vac; 1in threaded port + 1in swivel adapter |
| Construction | Aluminum housing (lower vibration) |
| Power | Pneumatic (compressed air) |
| Air consumption | 17 CFM (481 lpm) |
| Speed | 12,000 rpm |
| Power output | .28 hp (209 w) |
| Air inlet | 1/4in (6.4 mm) |
| Working pressure | 90 PSI (620 kPa) |
| Sound | 72 dBA (3in), 74 dBA (5-6in) |
| Weight | 1.6-2.0 lbs (0.71-0.93 kg) |
| Backup pad | J-Hook backup pad; also available as Vinyl pad (S suffix) |
| Included | 1in vacuum hose swivel adapter, ergonomic wrist support |
The HADI Technologies team will help you select the right configuration, verify application requirements and provide technical information about Clayton DuraLite 775 Pneumatic DA Random-Orbital Sander - Central Vac.
