The GB703V is a pneumatic-hydraulic tool designed specifically for the efficient installation of blind rivets. It weighs 5.50 lbs. (2.49 kg) and can be operated in any position. It has a 0.780" (19.81 mm) fastener setting stroke and a rated pull load of 2,200 lbs. (9.79 kN) with 90 psi (6.2 bar) air pressure at the air inlet. The GB703V installation tool operates on 90 to 100 psi (6.2 – 6.9 bar) of air pressure, with 90 psi (6.2 bar) providing the maximum efficiency. At 90 psi (6.2 bar) of air pressure, the GB703V does not exceed 81.5 dB(A) and consumes 0.16 SCF/cycle (4.53 L/cycle)
| Weight | 5.50 lbs. (2.49 kg) |
|---|---|
| Rated Pull Load | 2,200 lbs. (9.8 kN) |
| Stroke | 0.780" (19.8 mm) |
| Width | 11.47 (291.9 mm) |
| Noise Level | 81.5 dB(A) |
| Warranty | 1 year |
The HADI Technologies team will help you select the right configuration, verify application requirements and provide technical information about Gage Bilt Pneudraulic Rivet Tool GB703V.
