Clayton rectangular backup pads are the interface between the sander and the abrasive sheet, available in 3×4, 3×5, 3-2/3×7 and 2-3/4×8 inch sizes, plus a Corner version and Radius pads for sanding curves. They come in Hook, J-Hook and Vinyl attachment and Multi-Hole, Standard-Hole and No-Hole patterns.
Clayton rectangular backup pads are the interface between the sander and the abrasive sheet, available in 3×4, 3×5, 3-2/3×7 and 2-3/4×8 inch sizes, plus a Corner version and Radius pads for sanding curves. They come in Hook, J-Hook and Vinyl attachment and Multi-Hole, Standard-Hole and No-Hole patterns.
They mount to the sander two ways: Screw-On with 4 screws, or Peel & Stick pressure-sensitive adhesive. Multi-hole J-Hook pads come standard on all Clayton sanders for better airflow; J-Hook creates a small channel between the abrasive and the foam pad and is preferred for screen abrasives.
Radius pads are made for contour work: Radius Short (672-401J-56R, radius 56R, ~3.5″ diameter curve) and Radius Long (‘Dot’, 672-401J-66R, radius 66R, ~4.125″ diameter curve).
| SKU | Select |
| Size | Select |
| Attachment | Select |
| Hole pattern | Select |
| Mount | Select |
| Compatibility | Clayton dustless sanders – interfaces between the sander and the abrasive |
| Mounting methods | Screw-On – attaches with 4 screws; Stick-On – peel-and-stick adhesive |
| Attachment methods | Hook – short hooks; J-Hook – longer hooks that create an airflow/dust channel, preferred for screen abrasives; Vinyl – smooth vinyl surface with a few large dust-collection holes |
| Radius pads | Radius Short (56R) – ~3.5″ diameter curve; Radius Long (‘Dot’, 66R) – ~4.125″ diameter curve |
The HADI Technologies team will help you select the right configuration, verify application requirements and provide technical information about Clayton Rectangular Backup Pads for Dustless Sanders.
The right solution starts with a clear brief
The HADI product development and engineering team can adapt a tool, product or system to your application.
