MicroTorque test joints are offered in soft and hard configurations, in M2-M6 sizes and ranges from 0 to 1,000 cNm. The table lists drive, screw-head profile and part number for every configuration.
MicroTorque test joints are offered in soft and hard configurations, in M2-M6 sizes and ranges from 0 to 1,000 cNm. The table lists drive, screw-head profile and part number for every configuration.
| Model | Joint type | Range (cNm) | Drive | Screw head profile | Part number |
|---|---|---|---|---|---|
| M6 Soft joint | Soft | 500-1,000 | 1/4" Hex | HEX 5 mm | 8432083362 |
| M6 Soft joint | Soft | 200-500 | 1/4" Hex | HEX 5 mm | 8432083361 |
| M4 Soft joint | Soft | 27-200 | 1/4" Hex | HEX 3 mm | 8432083360 |
| M3 Soft joint | Soft | 5-27 | 1/4" Hex | HEX 2.5 mm | 8432083359 |
| M3 Soft joint | Soft | 5-27 | Ø 3 mm | HEX 2.5 mm | 8432083358 |
| M2 Soft joint | Soft | 0-10 | 1/4" Hex | HEX 1.5 mm | 8432083357 |
| M2 Soft joint | Soft | 0-10 | Ø 3 mm | HEX 1.5 mm | 8432083356 |
| M6 Hard joint | Hard | 200-1,000 | 1/4" Hex | HEX 5 mm | 8432083355 |
| M4 Hard joint | Hard | 27-200 | 1/4" Hex | HEX 3 mm | 8432083354 |
| M3 Hard joint | Hard | 5-27 | 1/4" Hex | HEX 2.5 mm | 8432083353 |
| M3 Hard joint | Hard | 5-27 | Ø 3 mm | HEX 2.5 mm | 8432083352 |
| M2 Hard joint | Hard | 0-10 | 1/4" Hex | HEX 1.5 mm | 8432083351 |
| M2 Hard joint | Hard | 0-10 | Ø 3 mm | HEX 1.5 mm | 8432083350 |
The HADI Technologies team will help you select the right configuration, verify application requirements and provide technical information about Atlas Copco MicroTorque Soft and Hard Test Joints.
