Atlas Copco RRC13B Pneumatic Scaler

A compact air-powered scaler for removing rust, scale, and coatings with precision.

Atlas Copco RRC13B Pneumatic Scaler

Atlas Copco RRC13B is a pneumatic scaler for effective work on hard surfaces and stubborn material removal.

It fits industrial tasks where a compact tool, fast blow action, and low free-speed air consumption matter on the line.

Key Features

  • Two product variants: The family includes two RRC13B versions with different accessory configurations.
  • Compact weight: The tool weighs 1.6 kg, which supports easier handling and control during longer tasks.
  • Fast blow action: The variants operate at a blow stroke frequency of 73 Hz or 98 Hz, depending on the version.
  • Low air consumption: Free-speed air consumption is 4.0 l/s or 4.9 l/s, depending on the model.
  • Standard air connection: Both versions use a 3/8″ BSP air inlet and a 10 mm rec hose size.
  • Included accessories: Each model comes with an adapter, and one version also includes a scaling chisel in 155 mm or 185 mm length.

Frequently Asked Questions

How do I choose between the two RRC13B versions?
Step 1: Check which accessory setup fits your task best.
Step 2: Compare the included chisel length in each version.
Step 3: Choose the version that matches your application, handling preference, and air setup.

What kind of work is the RRC13B suited for?
It is suited for cleaning and removal tasks with a pneumatic scaler, especially when a compact and easy-to-handle tool is needed.

What is the difference between the two versions?
The versions differ in blow stroke frequency, air consumption, and the included accessories.

What is included in the box?
An adapter is included.
One version also includes a 155 mm scaling chisel, while the other includes a 185 mm scaling chisel.

What air connection should be prepared?
The tool uses a 3/8″ BSP air inlet and a 10 mm rec hose size.

What should I check before ordering for my workshop or production line?
Check that the application matches the tool weight, air consumption, and the chisel setup supplied with the selected version.

ℹ️ Please note: this specification includes technical diagrams from the Atlas Copco catalog. The complete data and drawings are available in the PDF attached to this page (the “More details – PDF” button).

Atlas Copco RRC13B Scaler – Specifications

ModelLength (mm)Weight (kg)Blow (Hz)Stroke (mm)Energy per blow (J)Air consumption at free speed (l/s)Rec hose size (mm)Air inlet thread (in) BSP (in)Ordering No.
RRC13B2311.673351.44.0103/88425010133
RRC13B2311.698361.24.9103/88425010134

Accessories

The complete accessories tables, exactly as they appear in the Atlas Copco catalog – every ordering number, dimension and drawing. The PDF attached to this page is also available for download.

דף קטלוג עם טבלת אביזרים, כולל תושבת וכמה אזמלים שטוחים ומחודדים, לצד - Catalog page with an accessories table, including an adapter and several
